UV/IR Flame Detector
Honeywell C7027 A1049
The Honeywell C7027 A1049 is a self-diagnostic flame detector from the C70xx series (C7027/C7035/C7044), using triple-infrared sensing (2.9-3.1 / 4.4-4.7 / 5.0-5.2 um) to distinguish real flames from background radiation. Rated to IP66 and up to 50 m range, it integrates with burner management systems for mining, power and process applications.
Why buyers choose it
- Triple-IR discrimination cuts false alarms in harsh sites.
- Long 50 m range covers large industrial and mining spaces.
- IP66 rugged housing for dust and water exposure.
- Self-diagnostic sensing reduces maintenance downtime.
Specifications
| Model | Honeywell C7027 A1049 (series C7027/C7035/C7044) |
|---|---|
| Detection | Triple-IR: 2.9-3.1 / 4.4-4.7 / 5.0-5.2 um |
| Range | Up to 50 m |
| Enclosure | IP66 (dust/water resistant) |
| Compliance | NFPA 85 / NFPA 86 |
| Feature | Built-in self-diagnostics, multi-fuel compatible |
Applications
Mining tunnels and heavy industrial flame monitoring.
Power generation, chemical plants and waste-to-energy burners.
Buyer Questions
Honeywell C7027 A1049 FAQs
What does the Honeywell C7027 detect?
It is a triple-IR flame detector (2.9-3.1 / 4.4-4.7 / 5.0-5.2 um) from Honeywell's C70xx series, per the Zhongli Weiye product page.
What is its detection range and rating?
Up to 50 m range with an IP66 enclosure, compliant with NFPA 85/86.
Is it compatible with our burner management system?
It integrates with standard burner management systems; confirm interface (UV/IR, 4-20 mA) with Zhongli Weiye.
Request a quote for C7027 A1049
