Light Oil Burner
Riello RL100
The Riello RL100 two-stage light oil burner is designed for low and medium temperature hot water boilers, hot air or steam generators and diathermic oil boilers. A microprocessor-based control panel indicates burner status and fault causes, while optimized air suction and sound proofing reduce noise.
Applications
Hot water and steam boilers in food, chemical, paper, textile, paint and petroleum plants.
Hot air generators and diathermic oil boilers that need reliable two-stage oil firing.
Why buyers choose it
- Microprocessor control panel gives clear burner status and fault diagnostics.
- Optimized air suction circuit and built-in sound proofing reduce noise emissions.
- High-performance fan and combustion head maintain stable combustion across the firing range.
- Compact design simplifies installation and routine maintenance.
- Wide accessory range supports different boiler configurations.
Specifications
| Model | Riello RL100 |
|---|---|
| Output range | 356/711 - 1186 kW |
| Fuel | Light oil |
| Oil consumption | 30/60 - 100 kg/h |
| Electrical supply | 3/230-400 V / 50 Hz |
| Auxiliary supply | 230/50-60 V |
| Electrical power | 1.8 kW |
| Operation | Two-stage |
| Control panel | Microprocessor-based with status and fault indication |
| Certification | CE-0440/B |
| Typical code | 3475232 (TC FS1 3/230-400/50) |
Buyer Questions
Riello RL100 FAQs
What output does the Riello RL100 provide?
The Riello technical datasheet lists the RL100 firing range as 356/711 to 1186 kW, with an oil delivery of 30/60 to 100 kg/h on the 3/230-400 V / 50 Hz version.
Is the Riello RL100 suitable for steam boilers?
Yes, the RL series is designed for low and medium temperature hot water boilers, hot air or steam generators and diathermic oil boilers.
What fuel does the Riello RL100 use?
It is a light oil burner. A microprocessor-based control panel and two-stage operation are standard.
Request a quote for RL100 (960 T / 3475232)
