Gas Multibloc Valve
Dungs MB-ZRDLE 407 B01 S50 Gas Multibloc Valve
The Dungs MB-ZRDLE 407 B01 S50 is a gas multibloc valve in the Dungs MB-ZRDLE programme. The MB-ZRDLE 407 B01 S50 is the smaller DN25 multibloc in the S50 spring class, for compact gas trains that still want combined filtration, regulation and shut-off. It is brand dealer (ali-verified), cross-checked against the original before supply.
Overview
Dungs MB-ZRDLE 407 B01 S50 Gas Multibloc Valve at a glance
The Dungs MB-ZRDLE 407 B01 S50 shrinks the combined multibloc to a DN25 body for compact gas trains, while keeping the S50 spring class for a healthy flow band. It suits small and mid-size packaged boilers where space at the burner front is tight but the duty still wants a single device that filters, regulates and shuts off the gas. Specifiers pick the 407 over the 415 when the train simply does not need a DN40 pass-through; sizing to the body, not just the spring, avoids an oversized, costly valve.
Why buyers choose it
- The MB-ZRDLE 407 B01 S50 is the smaller DN25 multibloc in the S50 spring class, for compact gas trains that still want combined filtration, regulation and shut-off.
- Fitment: Fitted to small and mid-size packaged boilers where a DN25 Dungs multibloc keeps the burner front tidy.
Specifications
| Model | MB-ZRDLE 407 B01 S50 |
|---|---|
| Brand | Dungs |
| Type | Gas Multibloc Valve |
| Fuel | gas |
| Body | Aluminium gas multibloc (filter + regulator + valves) |
| Regulator | Adjustable gas pressure, S50 spring |
| Valves | Double solenoid, class A (automatic shut-off) |
| Size | DN25 combined multibloc |
| Max inlet | 500 mbar |
| Electrical | 230 V / 50 Hz coil |
| Supply | brand dealer (Ali-verified) |
| Warranty | 3 years on complete units & core components |
Applications
Fitted to small and mid-size packaged boilers where a DN25 Dungs multibloc keeps the burner front tidy.
Used where the S50 spring class is needed but the DN40 415 body would be oversized.
The MB-ZRDLE 407 B01 S50 is the dungs option Zhongli Weiye keeps in stock for gas burners in this class — chosen when gas multibloc valve simplicity and fast local supply matter more than extra features.
Buyer Questions
Dungs MB-ZRDLE 407 B01 S50 Gas Multibloc Valve FAQs
What does the MB-ZRDLE 407 B01 S50 do?
It is a gas multibloc valve in the Dungs MB-ZRDLE programme. The MB-ZRDLE 407 B01 S50 is the smaller DN25 multibloc in the S50 spring class, for compact gas trains that still want combined filtration, regulation and shut-off.
Which applications suit the MB-ZRDLE 407 B01 S50?
Fitted to small and mid-size packaged boilers where a DN25 Dungs multibloc keeps the burner front tidy. Used where the S50 spring class is needed but the DN40 415 body would be oversized.
How is the MB-ZRDLE 407 B01 S50 supplied and supported?
It is brand dealer (ali-verified) by Zhongli Weiye, cross-checked against the original part and your burner before supply, with a 3-year warranty on complete units & core components.
Is the MB-ZRDLE 407 the same as the 415?
No. Both share the S50 spring class, but the 407 is the DN25 combined multibloc and the 415 is the DN40 body. Size the body to the train's flow, not just the spring class.
Request a quote for MB-ZRDLE 407 B01 S50
